PS-QS-1×11-0783 ProSoft Technology EtherNet/IP to LonWorks Gateways

The QuickServer line of communication gateways are designed to link building automation drivennetworks with industrial control networks. The QuickServer gateways are available with limits of up to250 or 500 points of application data.

Features and Benefits
- Ability to interface up to 250 or 500 points of common BAS protocols depending on gateway
-Multi-configuration capability; specific configurations selectable via DIP switches or software
-DIN rail mount included with gateway
-DIP switches to select baud rate or node ID on the fly
-BACnet COV support for fast data communication while reducing the traffic over a BACnet network. BTL Marked (PS-QS-1X10-XXXX)

• Specifications
• Field Connections
• Ethernet 10/100 RJ45
• Serial RS-485 terminal (up to 115K baud)
• FTT-10 LonWorks port
• Environment
• Operating temperature: -40°F to 167°F (-40°C to 75°C)
• Relative humidity: 5% to 90% RH, with no condensation
• Power Requirements
• 9 to 30 Vdc or Vac or 5 Vdc
• Current draw 279mA @ 12Vdc Other
• Configuration/Diagnostic utilities
• Capacity: 250 or 500 Points
• Table, Wall or DIN rail mount
• Physical Dimensions (WxDxH)
• 4.5 x 3.2 x 1.6 in. (11.5 x 8.3 x 4.1 cm)
• 0.4 lbs (0.2 Kg)
• Approvals
• TUV approved to UL 916 standard
• CE Mark
• BTL Mark (PS-QS-1010)
• RoHS Compliant
• FCC Part 15 Compliant
